Dedicated line (CaseACf)
11 in Slop 2 \on coniK'clcit llio Son\ l.ll’-X 100 to a doilicatci.1 phone
line (no \oiee ealls ieeei\ei.n that has no lUher equipment eonneeted
to tt, then nse this eotineettoti diaetatii.
Phono optional,
-btit ic'ionmu'iKk'd
ToU'pliono
wall jack
• Connect your phone to the Sony IJP-V'IOO. Cotiticct the cord
IVotii your phone lo either of the two ports on the back of the Sotiy
IJP-V100 labelled, “To Phone, Answering Machine, or Modem."
The benelits of connecting a phone in this situation are 1) For the
convetiience of having a phone close by to make outgoing voice
calls, and 2) In case you need to .send a fax (press START) after
calling someone who must receive their faxes manually,
• After you install the software in Step 7, and answer the Setup
Wizard questions for this connection ca.se, here’s how you’ll auto­
matically receive faxes with the Sony IJP-V 100:
Your fax line will
ring once, then the Sony IJP-V100 will answer and begin emitting
fax tones to the sending machine.
• Continue with Step 7, “Install the Software - REQUIRED!”
Dedicated line with a PC-modem (Case ACH)
If in Step 2 you connected the Sony IJP-V 100 to a dedicated phone
line (no voice calls received) that also has a PC-modem connected to
it, then use this connection diagram.
Phone optional,
but recommended
PC with
internal modem Telephone
wall jack
1-10
