Identifying the parts
I
Eyecup RELEASE knob
(p. 69)
I
EJECT switch (p. 12)
I
LANC C control jack
C
stands for Local Application Control
Bus System. The
C
control jack is used
for controlling the tape transport of
video equipment and peripherals
connected to it. This jack has the same
function as the jack indicated as
CONTROL L or-REMOTE.
Cassette compartment
(p. 12)
Grip stfap
(p.'19)
I
RFU DC OUT (RFU adaptor DC output)
jack
(p. 55)
I
Viewfinder lens adjustment ring
(p. 14)
S VIDEO jack
(CCD-TRV65/TRV615
otdy) (p. 55)
VIDEO/AUDIO jacks (p. 54)
D (headphones) jack
(CCD-TRV65/
TRV615 only) (p. 23) /©
(earphone)
jack
(CCD-TRV15/TRV25/TRV35/
TRV215/TRV315 only) (p. 23)
82
