Specifications
Video camera ,
recorder i
% <
System
Video recording system
CCD-TRV65/TRV615;
4 rotary heads
(SP/LP independent heads)
CCD-TR V15 / TRV25 / TR V35 /
TRV215/TRV315:
2 rotary heads
Helical scanning FM system
Audio recording system
Rotary heads, FM system
Video signal
NTSC color, EIA standards
Usable cassette
8mm video format cassette
CCD-TRV15/TRV25/TRV35/
TRV215/TRV315;
Standard 8
CCD-TRV65/TRV615; Hi8 or
standard 8
Recording / Playback time (using
120 min. cassette)
SP mode: 2 hours
LP mode: 4 hours
Fastforward/rewind time (using
120 min. cassette)
Approx. 5 min.
Image device
CCD (Charge Coupled Device)
Viewfinder
Electronic viewfinder
Monochrome
Lens
Combined power zoom leps
Filter diameter 1 7/16 in. (37 mm)
CCD-TRV15/TRV25/TRV215:
16
X (Optical), 64 X (Digital)
CCD-TR V35 / TR V65 / TR V315 /
TRV615:
18 X (Optical), 72 x (Digital)
Focal distance
CCD-TR V15 / TR V25 / TRV215:
336 - 2 58 in. (4.1 - 65.6 mm)
CCD-TRV35/TRV65/TRV315/
TRV615:
316 - 8 in. (4.1 - 73.8 mm)
When converted to a 35 mm still
camera
CCD-TRV15:
1 916 - 24 7/« in. (39.4 - 630 mm)
CCD-TRV25/TRV215:
1 7/8 - 29 34 in. (47.2 - 755 mm)
CCD-TR V35 / TR V65 / TR V315 /
TRV615:
1 7/8 - 33 L2 in. (47.2 - 850 mm)
Color temperature
Auto
Minimum illumination
CCD-TRV15: 0.4 lux (F1.4)
CCD-TR V25 / TRV35/ TRV65 /
TRV215/TRV315/TRV615:
0.7 lux (F1.4)
CCD-TRV35/TRV65/TRV315/
TRV615.
0 lux ( in NightShot mode)*
* Object invisible for the dark can
be shot with infrared lighting.
Illumination range
CCD-TRV15:
0.4 lux to 100,000 lux
CCD-TR V25 / TRV35 / TRV65 /
TRV215/TRV315/TRV615:
0.7 lux to 100,000 lux
Recommended illumination
More than 100 lux
2.5 inches measured diagonally
2
X 1 1 /2 in. (50.3 X 37.4 mm)
On-screen display
TN LCD/TFT active matrix
method
Total dot number
61,380 (279
X 220)
'Input and output connectors
S video input/output
(CCD-TRV65/TRV615 only)
4-pin mini DIN
Luminance signal: 1 Vp-p, 75
ohms, unbalanced
Chrominance signal: 0.286 Vp-p,
75 ohms, unbalanced
Video input (CCD-TRV65/TRV615
only)/output
Phono jack, 1 Vp-p, 75 ohms,
unbalanced
Audio input (CCD-TRV65/TRV615
only)/output
CCD-TRV15/TRV25/TRV35/
TRV215/TRV315: Monaural,
Phone jack, 327 mV
CCD-TRV65/TRV615: Phono jacks
(2: stereo L and R)
327 mV, (at output impedance
47 kilohms) impedance less than
2.2 kilohms
RFU DC OUT
Special minijack, DC 5V
Headphone jack (CCD-TRV65/
TRV615only)
Stereo minijack (o 3.5 mm)
Earphone jack (CCD-TRV15/
TRV25n-RV35/TRV2157TRV315
only)
Monaural minijack
(0 3.5 rtun)
LANC control jack
Stereo mini-minijack (0 2.5 mm)
MIC jack
Minijack, 0.388 mV low impedance
with 2.5 to 3.0 V DC, output
impedance 6.8 kilohms
(0 3.5 mm)
CCD-TRV15/TRV25/TRV35/
TRV215/TRV315:
Monaural type
CCD-TRV65/TRV615: Stefeo type
Speaker
Dynamic speaker
Intelligent accessory shoe
(CCD-TRV65/TRV615 only)
8-pin cormector
(to be continued)
