Watching on a TV screen
Connect the camcorder to your TV or VCR to watch the playback picture on the TV
screen. When monitoring the playback picture by connecting the camcorder to your TV,
we recommend you to use house current for the power source.
While playing back on a TV screen, close the LCD panel. Otherwise, picture distortion
may occur.
mm
When connecting the A/V connecting cable, make sure you connect the plug to jacks of
the same color.
Open the jack cover. With using the supplied A/V connecting cable, connect the
camcorder to the LINE IN inputs on the TV or VCR connected to the TV. Set the TV /
VCR selector on the TV to VCR. When connecting to the VCR, set the input selector on
the VCR to LINE.
CCD-TRV15ATRV25/rRV35/TRV215/TRV315
: Signal flow
54
