CDP-338ESD/608ESD
Ref.No Part No.
Description
Ref.No
Part No.
Description
D922
8-719-230-02
DIODE 31DF2
Q806
8-729-900-45
TRANSISTOR DTC114EF
D923
8-719-230-02
DIODE 31DF2
Q807
8-729-900-45
TRANSISTOR DTC114EF
D924
8-719-230-02
DIODE 31DF2
Q808
8-729-967-32
TRANSISTOR 2SC2673
D951
8-719-107-94
DIODE 1SS202-1
Q901
8-729-167-62
TRANSISTOR 2SC2676
D952
8-719-107-94
DIODE 1SS202-1
Q902
8-729-113-82
TRANSISTOR 2SA1138-F
D953
8-719-110-78
DIODE RD33ES-B2
Q903
8-729-107-53
TRANSISTOR 2SC2275-A
D970
8-719-200-82
DIODE 11ES2
Q904
8-729-190-53
TRANSISTOR 2SA985-P
D971
8-719-200-82
DIODE 11ES2
Q905
8-729-113-82
TRANSISTOR 2SA1138-F
D972
8-719-200-82
DIODE 11ES2
Q906
8-729-167-62
TRANSISTOR 2SC2676
D973
8-719-107-94
DIODE 1SS202-1
Q907
8-729-167-62
TRANSISTOR 2SC2676
D974
8-719-107-94
DIODE 1SS202-1
Q908
8-729-113-82
TRANSISTOR 2SA1138-F
D975
8-719-937-49
DIODE RDF02M
Q910
8-729-900-80
TRANSISTOR DTC114ES
Q951
8-729-140-97
TRANSISTOR 2SB734
F990
A-1-532-066-11
(AEP, UK)....FUSE, TIME-LAG T0.4A
F990
A.1-532-279-00
(E)....FUSE, TIME-LAG T0.5A
RESISTOR
F990
A.1-532-741-11
(US, CND)... .FUSE, GLASS TUBE 1.25A 125V
RlOl
1-247-806-11
CARBON
91
5%
1/4W
FLD801 1-519-476-11
INDICATOR TUBE, FLUORESCENT
R102
1-249-512-11
CARBON
22
5%
1/4W
R103
1-249-417-11
CARBON
IK
5%
1/4W
ICIOI
8-752-034-00
1C CXA1081S
R104
1-249-433-11
CARBON
22K
5%
1/4W
IC201
8-752-035-28
1C CXA1291P
R105
1-249-421-11
CARBON
2.2K
5%
1/4W
IC202
8-752-035-28
1C CXA1291P
IC2Û4
8-752-032-33
1C CXA1182S
R106
1-249-428-11
CARBON
8.2K
5% 1/4W
IC302
8-752-325-59
1C CXD1165Q
R107
1-247-860-11
CARBON
16K
5%
1/4W
R108
1-249-425-11
CARBON
4.7K
5%
1/4W
IC351
8-759-631-47
1C M50747-161SP
R109
1-249-425-11
CARBON
4.7K
5%
1/4W
IC352
8-759-820-64
1C LC9600R-183
RllO
1-249-432-11
CARBON
18K
5%
1/4W
IC353
8-752-328-61
1C CXD1244S
IC354
8-759-978-53
1C CXD8003S
Rill
1-249-432-11
CARBON
18K
5%
1/4W
IC355
8-759-202-12
1C TC74HC02P
R112
1-249-441-11
CARBON
lOOK
5%
1/4W
R201
1-249-393-11
CARBON
10
5%
1/4W
IC356
8-759-202-13
1C TC74HCU04P
R203
1-249-393-11
CARBON
10
5%
1/4W
IC357
8-759-202-13
1C TC74HCU04P
R205
1-249-441-11
CARBON
lOOK
5%
1/4W
IC358
8-759-604-29
1C M5F7805
IC380
8-759-981-85
1C RC4556D
R206
1-247-881-00
CARBON
120K
5%
1/4W
IC390
8-759-977-71
1C GP1F31T
R208
1-249-441-11
CARBON
lOOK
5%
1/4W
R210
1-247-881-00
CARBON
120K
5%
1/4W
IC401
8-759-979-08
1C PCM58P-J
R211
1-249-437-11
CARBON
47K
5%
1/4W
IC402
8-759-982-03
1C RC5532DD
R212
1-249-435-11
CARBON
33K
5%
1/4W
IC501
8-759-979-08
1C PCM58P-J
IC502
8-759-982-03
1C RC5532DD
R214
1-247-846-11
CARBON
4.3K
5%
1/4W
IC801
8-752-806-27
1C CXP5058H-162Q
R216
1-249-393-11
CARBON
10
5%
1/4W
R217
1-247-899-11
CARBON
680K
5%
1/4W
IC802
8-749-920-03
1C GP1U52
R218
1-249-441-11
CARBON
lOOK
5%
1/4W
IC803
8-759-962-08
1C BA6208
R219
1-249-424-11
CARBON
3.9K
5%
1/4W
IC901
8-759-604-39
1C M5F78M12
IC951
8-759-604-29
1C M5F7805
R222
1-247-882-11
CARBON
130K
5%
1/4W
IC952
8-759-604-47
1C M5F7905
R223
1-249-393-11
CARBON
10
5%
1/4W
R224
1-249-393-11
CARBON
10
5%
1/4W
J301
1-568-101-11
JACK, PIN 4P (LINE OUT)
R228
1-247-896-11
CARBON
510K
5%
1/4W
J302
1-566-922-21
JACK, PIN IP (DIGITAL OUT COAXIAL)
R229
1-249-431-11
CARBON
15K
5% 1/4W
J303
1-507-796-61
JACK, LARGE TYPE (PHONES)
R230
1-249-440-11
CARBON
82K
5% 1/4W
L350
1-410-509-11
INDUCTOR lOUH
R231
1-249-440-11
CARBON
82K
5%
1/4W
L351
*1-410-858-11
INDUCTOR OUH
R232
1-249-429-11
CARBON
lOK
5%
1/4W
L391
1-421-946-11
TRANSFORMER, PULSE
R233
1-249-414-11
CARBON
560
5%
1/4W
L801
1-408-080-00
INDUCTOR lOOUH
R234
1-249-441-11
CARBON
lOOK
5%
1/4W
L802
1-408-080-00
INDUCTOR lOOUH
R235
1-215-434-00
METAL
3.6K
1%
1/6W
M251
A-4608-362-A
MOTOR (L) ASSY (LOADING)
R236
1-249-433-11
CARBON
22K
5%
1/4W
R237
1-249-441-11
CARBON
lOOK
5%
1/4W
PS970
1-532-675-00
(AEP, UK, E)....LINK, 1C
R238
1-249-417-11
CARBON
IK
5%
1/4W
R239
1-249-417-11
CARBON
IK
5%
1/4W
QlOl
8-729-140-97
TRANSISTOR 2SB734
Q205
8-729-900-80
TRANSISTOR DTC114ES
R240
1-249-417-11
CARBON
IK
5%
1/4W
Q206
8-729-900-80
TRANSISTOR DTC114ES
R241
1-249-417-11
CARBON
IK
5%
1/4W
Q301
8-729-900-61
TRANSISTOR DTA114ES
R243
1-247-854-11
CARBON
9.1K
5%
1/4W
Q401
8-729-107-99
TRANSISTOR 2SC3622A-K
R244
1-247-854-11
CARBON
9.1K
5%
1/4W
R301
1-247-903-00
CARBON
IM
5%
1/4W
Q501
8-729-107-99
TRANSISTOR 2SC3622A-K
Q801
8-729-900-45
TRANSISTOR DTC114EF
R303
1-215-469-00
METAL
lOOK
1%
1/6W
Q802
8-729-900-45
TRANSISTOR DTC114EF
R304
1-215-469-00
METAL
lOOK
1%
1/6W
Q803
8-729-900-45
TRANSISTOR DTC114EF
R305
1-249-429-11
CARBON
lOK
5%
1/4W
Q804
8-729-900-45
TRANSISTOR DTC114EF
R306
1-249-441-11
CARBON
lOOK
5%
1/4W
R307
1-249-429-11
CARBON
lOK
5%
1/4W
Q805
8-729-900-45
TRANSISTOR DTC114EF
Note:
Note:
The components identi-
Les composants identifiés par
tied by mark /i\ or do.t-
une marque ^
sont critiques
ted line with mark ^
pour la sécurité.
are critical for safety.
Ne les
■emplacer que par une
Replace only with part
pièce portant le
numéro spéci-
-28-
number specified.
fiй.
