CDP-338ESD/608ESD
SECTION 5
ELECTRICAL PARTS LIST
NOTE;
• Due to standardization, replacements in the parts
list may be different from the parts specified in
the diagrams or the components used on the set.
• Items marked are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering these
items.
• If there are two or more same circuits in a set
such as a stereophonic machine, only typical
circuit parts may be indicated and capacitors and
resistors in other same circuits may be omitted.
CAPACITORS;
MF: m F, PF: ц ц Р .
RESISTORS
• All resistors are in ohms.
• F: nonflammable
COILS
e MMH: mH, UH: juH
SEMICONDUCTORS
In each case, U; д, for example;
UA...; juA..., UPA...; дРА...,
UPC...; дРС, UPD...; дРО...
• CND; Canadian model
The components identified by
rr^rk ^ or dotted line with mark
A are critical for safety,
f^place only with part number
specified.
Les composants identifiés par une
marque A sont critiques pour la
sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
Ref.No Part No. Description Ref.No Part No. Description
901 *1-629-023-11 PC BOARD, TIMER C208 1-136-155-00 FILM 0.015MF 5% 50V
902 *A-4655-076-A MOUNTED PCB, DISPLAY C209 1-136-161-00 FILM 0.047MF 5% 50V
903 *1-629-022-11 PC BOARD, HEADPHONE C210 1-164-159-11 CERAMIC O.IMF 50V
904 *1-629-024-11 PC BOARD, REMOCON VR C211 1-164-159-11 CERAMIC O.IMF 50V
905 *1-629-025-11 PC BOARD, REMOCON MO C212 1-123-333-00 ELECT lOOMF 20% 16V
906 1-533-183-11 HOLDER, FUSE C213 1-123-333-00 ELECT lOOMF 20% 16V
907 *1-535-688-11 TERMINAL C215 1-126-233-11 ELECT 22MF 20% 25V
908 * 1-629-020-11 PC BOARD, POWER C216 1-123-382-00 ELECT 3.3MF 20% 50V
909 *A-4651-225-A MOUNTED PCB, MAIN C217 1-136-165-00 FILM O.IMF 5% 50V
910 *1-629-017-11 PC BOARD, COAXIAL C218 1-123-382-00 ELECT 3.3MF 20% 50V
911 *1-629-016-11 PC BOARD, OPTICAL C219 1-136-159-00 FILM 0.033MF 5% 50V
912 *1-629-019-11 PC BOARD, LINE OUT C220 1-136-165-00 FILM O.IMF 5% 50V
913 A. 1-555-386-00 (E)....CORD, POWER C221 1-106-359-00 MYLAR 0.0047MF 5% 50V
913 A. 1-555-795-00 (AEP)....COAD, POWER C222 1-124-499-11 ELECT IMF 20% 50V
913 A. 1-556-035-00 (UK)....C0AD, POWER C223 1-124-927-11 ELECT 4.7MF 20% 50V
913 A. 1-557-577-11 (US, CND)....C0AD, POWER C224 1-126-233-11 ELECT 22MF 20% 25V
914 1-526-565-00 (E)....AC PLUG ADAPTOR C225 1-162-294-31 CERAMIC O.OOIMF 10% 50V
915 *1-629-359-11 PC BOARD, L.MOTOR C226 1-162-282-31 CERAMIC lOOPF 10% 50V
916 *1-629-360-11 PC BOARD, SWITCH C227 1-126-233-11 ELECT 22MF 20% 25V
917 A-4638-084-A SENSOR ASSY, SPEED C228 1-130-472-00 MYLAR 0.0012MF 5% 50V
918 A-4608-335-A MOTOR ASSY .LINEAR C229 1-164-159-11 CERAMIC O.IMF 50V
919 *1-628-390-11 PC BOARD, TRANSLATION C230 1-106-359-00 MYLAR 0.0047MF 5% 50V
920 A8-848-047-01 PICK UP. OPTICS (KSS-151A) C231 1-126-233-11 ELECT 22MF 20% 25V
921 deletion —---- --------- C232 1-164-159-11 CERAMIC O.IMF 50V
922 1-465-047-11 REMOTE COMMANDER (RM-D670) C233 1-164-159-11 CERAMIC O.IMF 50V
BUS351 *1-560-242-21 BUS BAR 4P C234 1-164-159-11 CERAMIC O.IMF 50V
BUS352 * 1-560-242-31 BUS BAR 5P C251 1-136-157-00 FILM 0.022MF 5% 50V
BUS353 * 1-560-242-31 BUS BAR 5P C252 1-136-157-00 FILM 0.022MF 5% 50V
BUS354 *1-566-959-11 BAR, BUS C302 1-126-233-11 ELECT 22MF 20% 25V
BUS900 * 1-560-242-21 BUS BAR 4P C303 1-161-379-00 CERAMIC O.OIMF 20% 16V
CAPACITOR C304 1-124-902-00 ELECT 0.47MF 20% 50V
C305 1-136-159-00 FILM 0.033MF 5% 50V
ClOl 1-164-088-11 CERAMIC O.OOIMF 50V C306 1-136-173-00 FILM 0.47MF 5% 50V
C102
1-124-443-00 ELECT lOOMF 20% 6.3V C307 1-164-159-11 CERAMIC O.IMF 50V
C105 1-162-198-31 CERAMIC 8.2PF 10% 50V C308 1-164-159-11 CERAMIC O.IMF 50V
C106 1-164-159-11 CERAMIC O.IMF 50V
C107 1-130-477-00 MYLAR 0.0033MF 5% 50V C309 1-164-159-11 CERAMIC O.IMF 50V
C321 1-164-159-11 CERAMIC O.IMF 50V
C108 1-136-159-00 FILM 0.033MF 5% 50V C350 1-164-159-11 (AEP, UK, E)....
C109 1-164-159-11 CERAMIC O.IMF 50V CERAMIC O.IMF 50V
CllO 1-126-233-11 ELECT 22MF 20% 25V C358 1-130-483-00 MYLAR O.OIMF 5% 50V
cm
1-136-153-00 FILM O.OIMF 5% 50V C359 1-130-483-00 MYLAR O.OIMF 5% 50V
C112 1-136-153-00 FILM O.OIMF 5% 50V
C360 1-136-165-00 FILM O.IMF 5% 50V
C113 1-126-233-11 ELECT 22MF 20% 25V C361 T-124-119-00 ELECT 330MF 20% 16V
C114 1-164-159-11 CERAMIC O.IMF 50V C362 1-136-920-00 FILM O.IMF 5% 50V
C115 1-161-375-00 CERAMIC 0.0022MF 30% 16V C363 1-136-920-00 FILM O.IMF 5% 50V
C116 1-130-480-00 MYLAR 0.0056MF 5% 50V C364 1-136-165-00 FILM O.IMF 5% 50V
C117 1-124-902-00 ELECT 0.47MF 20% 50V
C365 1-164-159-11 CERAMIC O.IMF 50V
C200 1-161-379-00 CERAMIC O.OIMF 20% 16V C366 1-123-382-00 ELECT 33MF 20% 50V
C201 1-123-333-00 ELECT lOOMF 20% 16V C367 1-136-165-00 FILM O.IMF 5% 50V
C202 1-123-333-00 ELECT lOOMF 20% 16V C368 1-102-950-00 CERAMIC 13PF 5% 50V
C203 1-164-159-11 CERAMIC O.IMF 50V C369 1-102-950-00 CERAMIC 13PF 5% 50V
C204 1-164-159-11 CERAMIC O.IMF 50V
C370 1-124-517-11 ELECT 470MF 20% 50V
C205 1-162-294-31 CERAMIC O.OOIMF 10% 50V C371 1-106-359-00 MYLAR 0.0047MF 5% 50V
C206 1-162-294-31 CERAMIC 0.001MF 10% 50V C372 1-136-920-00 FILM O.IMF 5% 50V
C207 1-164-159-11 CERAMIC O.IMF 50V C373 1-136-920-00 FILM O.IMF 5% 50V
