Timing chart for the Wide Resolution
signals
Wide Resolution
864
X
480 1072
x
600 1376
x
768
Pixel Clock (MHz)
34.238
53.9^
87.44
Idol (nsec)
29.207
18.539
11.436
IH
{ ¡ i s e c )
31.777
26.4
20.676
H-Active
( i i s e c )
25.235
19.874
15.736
H-Blank
( f t s e c )
6.542
6.526
4.94
H-Front porch
( f t s e c )
0.701
0.89’
0.366
(dots)
24
48
32
H-Sync
( f t s e c )
3.738
3.263
2.104
(dots)
128
176
184
H-Back porch
( f t s e c )
2.103
2.373
2.47
(dots)
72
128
216
H-Sync Polarity
-
-
-
V-TTI Time (Lines)
525
628
806
V-Addr Time (Lines)
480
600
768
V-Blank Start (Lines)
488
600
768
V-Blank Time (Lines)
29
28
38
V-Sync Start (Lines)
490
601
771
V Bottom Border
(Lines)
8
0
0
V Front Porch (Lines)
2
1
3
Ver Sync Time (Lines) 2
4
6
V Back Porch (Lines)
25
23
29
V Top Border (Lines)
8
0
0
V-Sync Polarity
+
+
+
m
Additional Information
