Specifications
RGB 1, 2 IN
Acceptable signal
Projection system
LCD panel
Lamp
Lens
NTSC video signal, RGB signal
(For details, see'page 9.)
3 LCD panels, 1 lens projection
system
1.35-inch TFT LCD panel
Approx. 1.54 million dots
(512,880 pixels)
1068.5
X
480 dots x 3 panels
XL-IOOU: HID lamp, 100 W
Large diameter hybrid lens F2.4
Screen size (measured diagonally)
KL-W7000: 37 inches (942 mm)
KL-W9000: 50 inches (1,272 mm)
Viewable image size (for RGB input)
KL-W7000: Approx. 36.3 inches
(921 mm) (diagonally)
Approx. 803
X
452 mm (w/h)
KL-W9000'. Approx. 49.1 inches
(1247 mm) (diagonally)
Approx. 1087
X
611 mm (w/h)
Deflection frequency
Horizontal: 31.5 to 50 kHz
Vertical: 50 to 85 Hz
Speaker output
Inputs/outputs
VIDEO 1, 2 and 3 IN
VIDEO OUT
S VIDEO (VIDEO 1, 3 IN only)
(4-pin mini-DIN):
Y: 1 Vp-p, 75 ohms
unbalanced, sync negative
C: 0.286 Vp-p (burst signal), 75
ohms
VIDEO (phono jacks):
1 Vp-p, 75 ohms unbalanced,
sync negative
AUDIO (phono jacks):
2 channels, 500 mVrms
Impedance: more than 47
kohms
S VIDEO (4-pin mini-DIN):
Y: 1 Vp-p, 75 ohms
unbalanced, sync negative
C: 0.286 Vp-p (burst signal), 75
ohms
VIDEO (phono jack):
1 Vp-p, 75 ohms unbalanced,
sync negative
AUDIO (phono jacks):
2 channels, 500 mVrms
Impedance: less than 5 kohms
Power requirement
Power consumption
VIDEO (D-sub 15-pin, female):
R, G, B: 0.7 Vp-p, positive, 75
ohms terminated
Sync on Green: 0.286 Vp-p
SYNC/HD: Composite sync:
TTL, high impedance,
sync positive/negative
Horizontal sync: TTL, high
impedance, sync positive/
negative
VD: Vertical sync: TTL, high
impedance, sync positive/
negative
AUDIO (RGB 1 IN) (phono
jacks)
2 channels, 500 mVrms
Impedance: more than 47 kohms
AUDIO (RGB 2 IN) (stereo
minijack)
500 mVrms
Impedance: more than 47 kohms
Front:5 W x 2 ( L / R )
Woofer: 20 W
phono jacks, 2 channels,
0 to 500 mVrms (audio out
variable, 100% modulation)
Impedance: less than 5 kohms
100 to 120 V A C , 50/60 Hz
Dimensions
Mass
Supplied accessories
190 W (MAX)
Standby mode: 2 W
KL-W7000: 920 x 825 x 390 mm
(36t / 4 x 3 2 1 / 2 x 1 53/8 inches)
( w / h / d )
KL-W9000: 1,228 x 1,055 x 565 mm
(483 / 8
X
415 / 8
X
221 / 4 inches)
( w / h / d )
KL-W7000: Approx. 30 kg
(68 lbs 2 oz)
KL-W9000: Approx. 43 kg
(106 lbs 8 oz)
Remote control RM-Y980 (1)
Size AA (R6) batteries (2)
AC power cord (1)
RGB signal cable (D-sub 15-pin
•«—► D-sub 15-pin) (1)
HD15-HD15 (male, without the
No. 9 pin) adaptor (1)
Macintosh adaptor (1)
Windows 95 Monitor
Information Disk (1)
Brackets (2)
Screws for brackets (2)
Buckle (1)
Hexagon head wrench (1)
Dust remover (1)
Optional accessories
Lamp unit XL-IOOU
Design and specifications are subject to change without
notice.
2 8 E N Additional Information
