Index to parts and
controls
Refer to the pages indicated in ( ) for details.
Front panel
m POWER switch/indicator
[U TV/VTR button
[3] INPUT SELECT button (43)
[
4
] Tape compartment
\5\
QUICK TIMER button
# REC
(recording) button
(43)
[
7
] O PLAY
button
[E
DUAL MODE SHUTTLE
ring
[E
TIMER
indicator
(34)
53 REC (recording) indicator
101
■ STOP
button
(43)
M II
PAUSE button (43)
M
CHANNEL buttons
M
REJECT button
m Remote sensor (5)
Display window
ISPLMPi
1
eeiree
I
8881
m VTR indicator (32)
fE Tape speed indicators (30)
[E AUTO TRACKING indicator (41)
[
4
] Tape operation indicators
fSl Line/channel indicator (30)
[E Timecounter/cIock(19,29)
[E Tape indicator
Rear panel
[Tl
AC IN
connector
m LINE IN AUDIO/VIDEO
jacks
(42)
[E LINE OUT AUDIO/VIDEO jacks (7,42)
[
4
] RF UNIT switch (44)
[E CABLE BOX CONTROL jack (8)
E VHF/UHF connectors (8,10,12,14,16)
48
I
Additional Infoimation
