Hookup 4
have cable TV).
Antenna hookup
A Use this hookup if you're using:
• VHF/UHF antenna (you get channels 2-13 and channels 14 and higher)
• UHF-only antenna (you get channels 14 and higher)
• separate VHF and UHF antennas
Rear of TV
VHF/UHF
connector on your
TV: A, B,orC
B Use this hookup if you're using a VHFonly antenna (you get channels 2-13 only)
Rear of TV
VHF/UHF
--®
or
or
VHF
UHF
VHF
04
UHF
Match the type of
connector on your
TV: A . B , o r C
B For connector types
B and C, no UHF
connection is
required.
if you cannot
connect your antenna
cable to the VCR directly
If your antenna
cable
is a flat
cable (300-ohm twin lead cable)^ attach an
external antenna connector (not supplied) so that you can connect the
cable to the VHF/UHF IN jack. If you have separate cables for VHF and
UHF antennas, you may use a U/V band mixer (not supplied). For
details, see page
44.
^4 I Getting started
