Additional Information
Self-diagnosis Function
This monitor is equipped with a self-diagnosis function. If
there is a problem with your monitor or computer(s), the
screen will go blank and the (1) indicator will either light up
green or fla.sh orange.
0 Indicator
If the C!) indicator is green
1 Remove any plugs from the video Input 1 and 2
connectors, or turn off the connected computer(s).
2 Press and hold the 9-*^ button for 2 seconds.
a
If all four color bars appear (wliite, red, green, blue), the
monitor is working properly. Reconnect the video input
cables and check the condition of your computer(s).
If the color bars do not app>ear, there is a potential
monitor failure. Inform your authorized Sony dealer of
the monitor's condition.
If the Cb indicator is flashing orange
Press the 0 button to turn the monitor off and on.
If the (!) indicator lights itp green, the monitor is
working properly.
If the Ô indicator is istill flashing, there is a potential
monitor failure. Count the number of seconds between
orangé flashes of the Ô indicator and inform your
authorized Sony dealer of the morütor's condition. Be
sure to note the model name and serial number of your
monitor. Also note the make and model of your
computer and video board.
Specifications
GDM-400PS
Picture tube
Viewable image size
Resolution
Standard image area
0.25 - 0.27 mm aperture grille pitch
19 inches measured diagonally
90-degree deflection
Approx. 365 X 273 mm (w/h)
(14 ^/a X 10 ^/4 inches)
18.0" viewing image
Horizontal; Max. 1600 dots
Vertical; Max. 1200 lines
Approx. 330 X 264 mm (vv/h)
(13 X 10 V 2 inches)
Deflection frequency
Approx. 352 X 264 mm (w/h)
(13 ^/a X 10 V j inches)
Horizontal; 30 to 94 kHz
Vertical: 48 to 160 Hz
AC input voltage/current
100 to 240 V, 50 - 60 Hz, 1.8 - 1.0 A
Max. 130 W
444 X 467 X 453 mm (w/h/d)
(17 V 2 X 18 V 2 X 17 7/g inches)
Approx. 25 kg (55 lb 2 oz)
See page 6
Power consumption
Dimensions
Mass
Supplied accessories
GDM-500PS
Picture tube 0.25 — 0.27 mm aperture grille pitch
21 inches measured diagonally
90-degree deflection
Approx. 403.8 X 302.2 mm (w/h)
(16 X 12 inches)
19.8" viewing image
Horizorital: Max. 1600 dots
Vertical; Max. 1200 lines
Approx. 388 X 291 mm (w/h)
(15 ^/a X 11 */2 inches)
or
Approx. 364 X 291 mm (w/h)
(14 ^/a X 11 ’/2 inches)
Horizontal: 30 to 107 kHz
Vertical; 48 to 160 Hz
AC input voltage/current
100 to 240 V, 50 - 60 Hz, 2.0 - 1.0 A
Max. 160 W
498 X 505 X 474 mm (w/h/d)
(19 */a X 20 X 18 ^/4 inches)
Approx. 31 kg (68 lb 5 oz)
See page 6
Viewable image size
Resolution
Standard image area
Deflection frequency
Power consumption
Dimensions
Mass ,
Supplied accessories
Design and specifications are subject to change without
notice.
