UNPACKING
When unpacking, check to make sure the following parts are included. All sizes listed below are
approximate. If any parts are missing or broken, please call Harbor Freight Tools at the number
on the cover of this manual.
ASSEMBLY
Your Air Ratchet comes completely assembled.
Air Connection for Ratchet
Step 1: Remove the plastic cap from the rear of the CONNECTION HEAD (#2).
Step 2: Wrap the threads of the Air Coupler with pipe thread seal tape (not included). Attach
the Air Coupler to the CONNECTION HEAD. Tighten the fitting.
Step 3: Your Air Ratchet is ready for use.
Impact Wrench
This Impact Wrench develops a maximum of 230 ft/lbs. of torque. The amount of torque can be
increased or decreased using the AIR REGULATOR (#11). When the Air Regulator is
completely screwed in it is at it’s lowest setting. Air pressure increases as you loosen the Air
Regulator.
Page #6 -- SKU: 33567 REV 12/02 REV 05/04
Item# Description Item# Description
N/A 3/8" Ratchet Wrench N/A Impact Sockets (7/16" – 1")
N/A 1/2" Impact Wrench N/A Oil Pot
N/A 3/8" to 1/2" Adapter N/A Air Coupler
N/A 4mm Hex Wrench
For technical questions, please call 1-800-444-3353.
