PARTS LIST – AIR IMPACT WRENCH
Item# Parts No. Description Item# Parts No. Description
1 16001 Housing 23 16023 Ball Bearing (X2)
2 16002 Valve Sleeve 24 16024 Cylinder
3 16003 Reverse Valve 25 16025 Rotor
4 16004 Trigger 26 16026 Rotor Blade (X6)
5 16005 Spring Pin 27 16027 Front End Plate
6 16006 Valve Stem 28 16028 Spring Pin
7 16007 Bushing 29 16029 Rear End Plate
8 16008 Steel Ball 30 16030 Spring Pin
9 16009 Spring 31 16031 Oil Seal
10 16010 Hose Adapter 32 16032 Rear Gasket
11 16011 Air Regulator 33 16059 O-Ring
12 16012 O-Ring 34 16033 Rear Cover
13 16013 Set Screw 35 16035 Cap Screw (X4)
14 16014 Spring 36 16036 Pin
15 16015 Anvil Bushing 37 16037 Spring
16 16016 Anvil Collar 38 16038 Set Screw
17 16017 O-Ring 39 16039 Exhaust Deflector
18 16018 Anvil 40 16040 Tapping Screw (X2)
19 16019 Hammer Cage 41 16041 Set Screw
20 16020 Hammer Pin 42 16042 Protecting Rubber
21 16021 Hammer Dog 43 16043 Rubber
22 16022 Drive Cam
Page #18 -- SKU: 33567 REV 12/02
For technical questions, please call 1-800-444-3353.
