Tightening
Step 1: Verify that the power level is correct for your needs and that the REVERSE VALVE
(#3) has been shifted (pressed) completely to the left. If not, refer to Steps 6 through 7
under
Impact Wrench Operation before proceeding.
Step 2: Place your work in as clear a location as possible. Make sure the air hose will reach as
far as needed without stressing any connections.
Step 3: Thread the nut or bolt on as far as possible by hand. This is to prevent cross-thread-
ing.
Step 4: If you have torque specs for the nut or bolt you are working on, refer to them. If a low
torque setting is given, it is recommended that you use a socket wrench or a manual
torque wrench to tighten as the Impact Wrench may provide too much torque, even in
the lowest power setting.
Step 5: Place the socket onto the nut or bolt.
Step 6: Grip the Impact Wrench with both hands, especially with higher power settings. Make
sure you are in a stable position and spread your feet shoulder-width apart.
Step 7: Press the TRIGGER to tighten the bolt.
Step 8: When the bolt is tight, release the TRIGGER. DO NOT OVER TIGHTEN!
MAINTENANCE
There are no user-serviceable parts in your Impact Wrench. Attempts to repair or make adjust-
ments on your tool are prohibited and will VOID your warranty.
Refer to OPERATIONS Setup for information on maintaining your tool.
Wipe down your tool after every use and store it in a drawer or other safe place.
WARRANTY
Air Tools covered under Central Pneumatic 1 year warranty.
Sockets covered under Pittsburgh Limited Lifetime warranty.
Page #15 -- SKU: 33567 REV 12/02 REV 04/04
For technical questions, please call 1-800-444-3353.
