Installation illustration caution – Tomei Powered HEADLIGHT AIR INTAKE (R34) User Manual
Page 5
5
INSTALLATION ILLUSTRATION
CAUTION
■ After confirming the mounting position, temporarily tighten the part in place with clamps.
Bend the brackets into shape if required.
HEADLIGHT REMOVAL
HEADLIGHT AIR INTAKE INSTALLATION
Use the supplied bolts with the stock nuts and bolts to fix the part in the 4 points.
If required, use a double sided tape on the bottom to assist with the installation.
Rubber seal
Clip
Screw
Screw
Headlamp
bolt
Bolt
Screw
