Tomei Powered HEAT SHEILD - Manual (Page 3)

KIT CONTENTS
Below are the parts included in this kit with the quantity no. in brackets ().
REQUIRED TOOLS These are the required tools for the installation.
・General Maintenance Tools ・Torque Wrench ・Service Manual
INSTALLATION
1. Remove the original heat shield.
2. The stock sensor harness will need to be tied
to a safe place so that it will not interfere with
anything during and after the installation process.
3. Install the Tomei Heat Sheild with the bolts supplied in the kit like in the illustration below.
［Torque Specs 14N・m(1.4kgf-m)]
3
HEAT SHEILD（1）
Heat Shield Bolt
・Long Bolt（4）
・Short Bolt（1）
Washer（5）
Tie Wrap（1）
Secure it to a safe place
Not used on EVO 4-6 models
※Short Bolt
