CY7C1386DV25, CY7C1386FV25
CY7C1387DV25, CY7C1387FV25
Document Number: 38-05548 Rev. *E Page 16 of 30
119-Ball BGA Boundary Scan Order [14, 15]
Bit # Ball ID Bit # Ball ID Bit # Ball ID Bit # Ball ID
1 H4 23 F6 45 G4 67 L1
2 T4 24 E7 46 A4 68 M2
3 T5 25 D7 47 G3 69 N1
4 T6 26 H7 48 C3 70 P1
5 R5 27 G6 49 B2 71 K1
6 L5 28 E6 50 B3 72 L2
7 R6 29 D6 51 A3 73 N2
8 U6 30 C7 52 C2 74 P2
9 R7 31 B7 53 A2 75 R3
10 T7 32 C6 54 B1 76 T1
11 P6 33 A6 55 C1 77 R1
12 N7 34 C5 56 D2 78 T2
13 M6 35 B5 57 E1 79 L3
14 L7 36 G5 58 F2 80 R2
15 K6 37 B6 59 G1 81 T3
16 P7 38 D4 60 H2 82 L4
17 N6 39 B4 61 D1 83 N4
18 L6 40 F4 62 E2 84 P4
19 K7 41 M4 63 G2 85 Internal
20 J5 42 A5 64 H1
21 H6 43 K4 65 J3
22 G7 44 E4 66 2K
Notes
14. Balls that are NC (No Connect) are preset LOW.
15. Bit #85 is preset HIGH.
