16
The following replacement parts list is keyed to the accompanying illustrations for
parts identification purposes. All replacement parts should be purchased from Taylor-
Wharton. When placing orders, please use the nomenclature and part numbers in
this section and send written orders to:
Taylor-Wharton FAX: 251-443-2250
4075 Hamilton Blvd. Phone: 251-443-8680
Theodore, AL 36582 In U.S.A. and Canada
U.S.A. (800) TW TANKS (898-2657)
REPLACEMENT
PARTS
Item No. Model Float Rod Part No.
* EC-150 GL45-9C91
* EC-300 GL45-9C93
* EC-450 GL45-9C97
* EC-600 GL45-9C97
*Not illustrated
Item Part Number Description
1 6916-9352 Check Valve, 1/4" NPT, Brass
2 6816-9927 Street Tee, 1/4", Brass
3 6913-9225 Pipe Away, 1/2" FNPT, Brass
4 6816-0100 Tee, Male Branch, .25 x .25 x .25, NPT, Brass, 300 PSIG
5 6913-9083 ASME Safety Relief Valve, 1/2" NPT, Brass
6 6010-2075 Plug, Pipe, 1/4", Square head, Brass
7 7815-3083 Safety Head, 450 PSIG
8 7355-4780 Connector, Male, 3/8" ODT x 1/4" MNPT, SS
9 6816-9215 Tee, Male Branch, 1/2" x 1/2" OD, Brass
10 6916-7111 Valve, Ball, 3/8" Inch Female
11 6816-9209 Street Tee, 3/8", Brass
12 6913-9075 Relief Valve, 3/8" MNPT, 400 PSIG, Brass
13 6919-9086 Valve, Ball, 1/4" FNPT x 1/4" MNPT
14 7355-4771 Connector, Male, 1/2" ODT x 3/8" MNPT, Brass
15 EC30-9C02 PB Tube
16 8816-1057 Regulator, PB, 125 PSI, 1/4" IN/OUT
17 GL50-9C54 Cover, Liquid Level Gauge
18 8816-1040 Regulator, 90 PSI, 1/4" IN/OUT
19 6460-2025 Washer, Lock, 1/4" STN.STL
20 6114-1088 Screw, Pan HD, .25-20UNC x .62, Brass
21 7702-6207 Pressure Gauge, 0-200 PSIG
22 EC30-9C01 Tube, Safety Vent
23 7701-0083 Gasket, Glass Filled Teflon
24 BC04-9C65 Float Gauge
25 7702-6206 Pressure Gauge, 0-400 PSIG
