UNIT
30HWA
DIMENSIONS — in. (mm)
A B C D E F G
018
12.58
(320)
19.20
(488)
20.48
(520)
33.85
(860)
11.72
(298)
5.75
(146)
17.95
(456)
025
12.82
(326)
18.98
(482)
20.57
(522)
33.85
(860)
11.72
(298)
5.75
(146)
17.95
(456)
028
12.64
(321)
18.31
(465)
20.73
(527)
33.85
(860)
11.72
(298)
5.75
(146)
17.95
(456)
035
12.87
(327)
18.62
(473)
20.81
(529)
33.85
(860)
11.72
(298)
5.75
(146)
17.95
(456)
040
12.66
(322)
18.64
(473)
21.30
(541)
34.15
(867)
11.34
(288)
8.22
(209)
17.36
(441)
DISCONNECT
(Amps)
LOCATION — in. (mm) MODEL 30HWA (See Table Below)
J K L M 018--- 025--- 028--- 035--- 040---
80
3.33
(85)
2.98
(76)
14.44
(367)
46.50
(1181)
100,200,
600,800,900
100,200,
600,900
100,200,
600,900
100,600,900 —
100
4.33
(110)
4.98
(126)
14.82
(376)
47.50
(1207)
500 500,800 800 200,800
100,200,
600,900
200
7.46
(189)
11.19
(284)
15.82
(402)
54.50
(1384)
— — 500 500 500,800
LEGEND
DISC. — Disconnect
K.O.
— Knockout
NOTES:
1. Denotes center of gravity.
2. Denotes accessory or factory-installed option.
3. Dimensions are in inches. Dimensions in ( ) are in millimeters.
MODEL VOLT-Hz
100 575-60
200 380-60
500 208/230-60
600 460-60
800 230-50
900 400-50
Fig. 6 — 30HWA018-040 (Condenserless)
LEFT SIDE VIEW
REAR VIEW
RIGHT SIDE VIEW
