Hard Drive

Dell™ Latitude™ E5400 and E5500 Service Manual



Removing the Hard Drive



Replacing the Hard Drive



Removing the Hard Drive







1.

Follow the procedures in

Before Working on Your Computer

.




2.

Close the display and turn the computer upside down.



3.

Remove the bottom of the base assembly (see

Removing the E5400 Bottom of the Base Assembly

or

Removing the E5500 Bottom of the Base

Assembly

).




4.

Remove the four M2 x 3-mm screws securing the hard drive.



5.

Pull on the mylar tab near the install arrow towards the front of the computer until it is removed from the connector.



6.

Lift out the hard drive by the tab and remove it from the computer.



Replacing the Hard Drive





1.

Slide the hard drive toward the back of the computer into the hard drive connector until the drive is fully seated.



2.

Replace the four M2 x 3-mm screws that secure the hard drive.



NOTE:

Dell does not guarantee compatibility or provide support for hard drives obtained from sources other than Dell.

CAUTION:

Before you begin any of the procedures in this section, follow the safety instructions that shipped with your computer. For additional

safety best practices information, see the Regulatory Compliance Homepage on www.dell.com at: www.dell.com/regulatory_compliance.

CAUTION:

Do not touch the metal housing of the hard drive if you remove the hard drive from the computer while the drive is hot.

NOTICE:

To prevent data loss, turn off your computer before removing the hard drive. Do not remove the hard drive while the computer is on or in

Sleep state.

NOTICE:

Hard drives are extremely fragile. Exercise care when handling the hard drive.

1 M2 x 3-mm screws (4) 2 hard drive

NOTICE:

When the hard drive is not in the computer, store the drive in protective antistatic packaging.

CAUTION:

Before you begin any of the procedures in this section, follow the safety instructions that shipped with your computer. For additional

safety best practices information, see the Regulatory Compliance Homepage on www.dell.com at: www.dell.com/regulatory_compliance.

NOTICE:

Hard drives are extremely fragile. Exercise care when handling the hard drive.

NOTICE:

Use firm and even pressure to slide the hard drive into place. Excessive force may result in damage to the connector.

NOTE:

This procedure assumes that you have completed the removal procedure first.
