Fan
Dell™ Latitude™ E5400 and E5500 Service Manual
Removing the Fan
1.
Follow the instructions in
Before Working on Your Computer
.
2.
Remove the bottom of the base assembly (see
Removing the E5400 Bottom of the Base Assembly
or
Removing the E5500 Bottom of the Base
Assembly
).
3.
Remove the two M2.5 x 8-mm screws that secure the fan to the base of the computer.
4.
Disconnect the fan connector from the system board connector, and remove the fan.
Replacing the Fan
1.
Align the screw holes on the fan with the holes on the base of the computer.
2.
Replace the two M2.5 x 8-mm screws to secure the fan to the base of the computer.
3.
Connect the fan connector to the system board connector.
4.
Replace the bottom of the base assembly (see
Replacing the E5400 Bottom of the Base Assembly
or
Replacing the E5500 Bottom of the Base Assembly
).
5.
Follow the procedures in
After Working on Your Computer
.
