80
Installing System Components
CAUTION:
The processor and heat sink can get very hot during normal operation.
Ensure that they have had sufficient time to cool before you touch them.
1 Turn off the system and attached peripherals, and disconnect the system
from the electrical outlet.
2 Open the system. See "Opening the System" on page 47.
3 Detach the diskette cable that is braced on top of the shroud assembly and
move it aside.
4 Using a #2 Phillips screwdriver, loosen the two captive screws holding the
heat sink and shroud assembly in place.
These captive screws are adjacent to the processor cooling fan housing. See
Figure 3-21.
5 Tilt the heat sink and shroud assembly away from the fan housing on its
pivot bracket and lift it out.
