Dell Latitude D630 ATG (Mid 2007) - Manual (Page 145)

Specifications 145
Width 73.0-mm (2.9-inch) sensor-active area
Height 42.9-mm (1.7-inch) rectangle
Track Stick
X/Y position resolution
(graphics table mode) 250 count/sec @ 100 gf
Size protrudes 0.5 mm higher than surrounding
keycaps
Battery
Type
9-cell "smart" lithium ion (85 WHr)
6-cell "smart" lithium ion (56 WHr)
Dimensions:
4-cell and 6-cell lithium-ion
batteries:
Depth 66.6 mm (2.62 inches)
Height 19.2 mm (0.76 inch)
9-cell lithium-ion batteries:
Depth 93.3 mm (3.67 inches)
Height 20.59 m (0.81 inch)
Weight 0.51 kg (1.12 lb) (9 cell)
0.33 kg (0.73 lb) (6 cell)
0.24 kg (0.53 lb) (4 cell)
Voltage 11.1 VDC (6 cell and 9 cell)
14.8 VDC (4 cell)
Touch Pad
