Adding and Replacing Parts 135
Media Bay
NOTE: If the device locking screw is not present, you can remove and install devices while the computer is
running and connected to a docking device (docked).
Removing Media Bay Devices
NOTICE: To prevent damage to devices, store them in a safe, dry place when they are not installed in the
computer. Avoid pressing down on them or placing heavy objects on top of them.
1 If present, remove the device locking screw from the bottom of the computer.
2 If the computer is running, double-click the Safely Remove Hardware icon on the taskbar, click the
device you want to eject, and click Stop.
3 Press the device latch release.
4 Pull the device out of the media bay.
To install a device, push the new device into the bay until it clicks into place.
FCM (Flash Cache Module) Card
The FCM card is an internal flash drive that helps improve the performance of your computer.
NOTE: This card is only compatible with the Microsoft Windows Vista® operating system.
NOTE: If you ordered a FCM card with your computer, the card is already installed .
1 optical drive 2 device latch release
1
2
