34 | Copying
Margin shift
The Margin Shift feature allows you to create a binding edge for the
document. The image can be adjusted up or down on the page and/or
shifted to the right or left.
1. Press Copy.
2. Load originals face up into the DADF, or place a single
original face down on the scanner glass.
For details about loading an original, see "Loading
originals" on page 23.
3. Press Menu ( ) until Copy Feature appears on the
bottom line of the display and press OK.
4. Press OK when Margin Shift appears.
5. Press the left/right arrow until the binding option you want appears.
• Off: This feature is disabled.
• Auto Center: Automatically copy in the center of the paper.
• Custom Margin: Enter the left, right, top, bottom margin using
Number keypad.
6. Press the left/right arrow to select Yes.
7. Press OK to begin copying.
8. Press Stop/Clear (
) to return to Ready mode.
Edge erase
Edge erase allows you to erase sports, drill holes, fold creases and staple
marks along any of the four edges of a document.
1. Press Copy.
2. Load originals face up into the DADF, or place a single
original face down on the scanner glass.
For details about loading an original, see "Loading
originals" on page 23.
3. Press Menu ( ) until Copy Feature appears on the
bottom line of the display and press OK.
4. Press OK when Edge Erase appears.
5. Press the left/right arrow until the binding option you want appears.
• Off: Does not set the binding option.
• Small Original: Erases the edge of the original if it is small.
• Hole Punch: Erases the marks of bookbinding holes.
• Book Center: Erases the middle part of the paper which is black
and horizontal, when you copy a book.
• Border Erase: Erases the certain amount of the edge of the
printout.
6. Press OK to begin copying.
7. Press Stop/Clear (
) to return to Ready mode.
Gray enhance copying
When you copy the original in gray scale, use this feature for the better
quality of copy-output. This feature is only for the copy in gray scale.
1. Press Copy.
2. Load originals face up into the DADF, or place a single original face
down on the scanner glass.
For details about loading an original, see "Loading originals" on
page 23.
3. Press Menu ( ) until Copy Feature appears on the bottom line of the
display and press OK.
4. Press OK when Gray Enhance appears.
5. Press the left/right arrow to select On.
6. Press OK to begin copying.
7. Press Stop/Clear (
) to return to Ready mode.
PRINTING ON BOTH SIDES OF PAPER
By using the Duplex ( ) button on your printerprinter, you can set the
printer to print documents on both sides of paper.
1. Press Copy.
2. Press Duplex ( ).
3. Press the left/right arrow until the binding option you want appears.
• Off: Copys in Normal mode.
• 1->2Side Short: Copys pages to be read by flipping like a note pad.
• 1->2Side Long: Copys pages to be read like a book.
• 2 ->1Side: Copys both sides of the originals and prints each of one on
a separate sheet.
• 2 ->2Side: Copys both sides of the original and prints on both sides
of the paper. This function produces exactly the same print out from
the originals.
• 2 ->1Side ROT2: Copys both sides of the original and prints each one
on a separate sheet, but the information on the back side of the printout
is rotated 180°.
4. Press OK to save your selection.
If the mode is enabled, the Duplex ( ) button is backlit.
The Margin Shift feature can either be used for Scan glass or DADF
depending on the set up.
-Auto Center: Scanner glass
-Custom Margin: Scanner glass, DADF
The Edge Erase feature can either be used for scan glass or DADF
depending on the set up.
-Small Original: Scanner glass
-Hole Punch: Scanner glass, DADF
-Book Center: Scanner glass
-Border Erase: Scanner glass, DADF
X Y
X Y
X Y
