Setting Up and Using Your Computer 29
Bottom View
F A N — The computer uses an internal fan to create airflow through the vents,
which prevents the computer from overheating.
D
E VI C E L A T C H R EL E AS ES — Press a latch release to remove a device in the
module bay or battery bay. See page 38.
M
E MO R Y M O D U L E , M I N I PCI C A R D , A ND M O D E M C O VE R — Protects
the memory module(s) and the optional modem. See page 93.
D
O C KI NG D EV I C E L A T C H — Latches onto the docking device.
memory module, Mini PCI
card, and modem cover
device latch releases
docking device latch
fan
