Technical Specifications
Dell™ PowerEdge™ 2500 Systems User's Guide
Table A-1. Technical Specifications
Microprocessor
Microprocessor type Intel® Pentium™ III microprocessors with a minimum internal operating frequency of 933 MHz and an external operating frequency
of 133 MHz
Front side bus speed 133 MHz
Internal cache 256 KB Level 2 cache
Expansion Bus
Bus type PCI
Expansion slots 2 64-bit, 66-MHz slots
3 64-bit, 33-MHz slots
2 32-bit, 33-MHz slots
Memory
Architecture 72-bit ECC PC-133 SDRAM, 2-to-1 interleaved
Memory module sockets six
Memory module capacities 64-, 128-, 256-, 512 MB or 1 GB
Minimum RAM 128 MB (with 64 MB memory modules)
Maximum RAM 4 GB
Drives
Diskette drive 3.5-inch, 1.44-MB diskette drive
Tape drive optional internal and external tape drives
SCSI devices eight 1-inch, internal, hot-pluggable Ultra3 SCSI hard-disk drive bays
CD-ROM drive one IDE CD-ROM drive
Ports and Connectors
Externally accessible:
Serial (DTE) two 9-pin connectors; 16550-compatible
Parallel one 25-pin connector (bidirectional)
Video one 15-pin connector
PS/2-style keyboard 6-pin mini-DIN connector
PS/2-compatible
mouse 6-pin mini-DIN connector
USB two USB-compliant 4-pin connectors
NIC RJ45 connector for integrated NIC
Internally accessible:
SCSI channels two 68-pin Ultra3 SCSI connectors
Video
Video type ATI Rage XL video controller; VGA connector
Video memory 8 MB
Power
DC power supply:
Wattage up to three 300-W power supplies in a 2 +1 redundant configuration (600 usable watts)
Voltage 90-240V, 47/63 Hz
System battery CR2032 3.0-V lithium coin cell
Physical
