122
Adding and Replacing Parts
3 Turn the computer over, loosen the captive screws on the memory module cover, and then remove the
cover.
NOTICE:
To prevent damage to the memory module connector, do not use tools to spread the memory-module
securing clips.
4 If you are replacing a memory module, remove the existing module:
a Use your fingertips to carefully spread apart the securing clips on each end of the memory module
connector until the module pops up.
b Remove the module from the connector.
NOTE:
If the memory module is not installed properly, the computer may not boot properly. No error message
indicates this failure.
1 memory module 2 securing clips
(2 per connector) 3 memory module connector
1
2
3
