Palm Rest
Dell™ Inspiron™ 910 Service Manual
Removing the Palm Rest
1.
Follow the instructions in
Before You Begin
.
2.
Remove the module cover (see
Removing the Module Cover
).
3.
Remove the keyboard (see
Removing the Keyboard
).
4.
Turn the computer over and remove the left and right rubber bumpers.
5.
Remove the nine screws from the computer base.
6.
Turn the computer over and remove the seven screws from the top of the palm rest.
7.
Disconnect the Bluetooth card cable, touch pad cable, and the power button cable from the respective system board connectors.
CAUTION:
Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
NOTICE:
To avoid electrostatic discharge, ground yourself by using a wrist grounding strap or by periodically touching an unpainted metal surface (such
as the back panel) on the computer.
1
left rubber bumper
2
screw (9)
3
right rubber bumper
