3. Insert the Mini-Card at a 45-degree angle into the appropriate system board connector. For example, the WLAN card connector is labeled WLAN and so
on.
4. Press the other end of the WLAN card down into the slot on the system board and replace the two securing screws.
5. Connect the appropriate antenna cables to the Mini-Card you are installing. The following table provides the antenna cable color scheme for each Mini-
Card supported by your computer.
6. Secure unused antenna cables in the protective mylar sleeve.
7. Replace the module cover (see Replacing the Module Cover ).
8. Slide the battery into the battery bay, until it clicks in place and slide the battery-lock latch to the lock position.
9. Install the drivers and utilities for your computer, as required. For more information, see the Dell Technology Guide.
Back to Contents Page
Connectors on the Mini-Card Antenna Cable Color Scheme
WWAN (2 antenna cables)
Main WWAN (white triangle)
Auxiliary WWAN (black triangle)
white with gray stripe
black with gray stripe
WLAN (2 or 3 antenna cables)
Main WLAN (white triangle)
Auxiliary WLAN (black triangle)
white
black
WPAN (one antenna cable)
WPAN blue
NOTE: If you are installing a communication card from a source other than Dell, you must install the appropriate drivers and utilities. For more
information, see the Dell Technology Guide.
