Coin-Cell Battery
Dell™ Inspiron™ 910 Service Manual
Removing the Coin-Cell Battery
Replacing the Coin-Cell Battery
Removing the Coin-Cell Battery
1.
Follow the instructions in
Before You Begin
.
2.
Remove the module cover (see
Removing the Module Cover
).
3.
Remove the keyboard (see
Removing the Keyboard
).
4.
Remove the palm rest (see
Removing the Palm Rest
).
5.
Remove the display assembly (see
Display Assembly
).
6.
Remove the system board (see
Removing the System Board
).
7.
Turn the system board over.
8.
Disconnect the coin-cell battery cable from the system board connector.
9.
Remove the coin-cell battery.
Replacing the Coin-Cell Battery
1.
Replace the coin-cell battery.
2.
Connect the coin-cell battery cable to the system board connector and hold the coin-cell battery in place.
3.
Replace the system board (see
Replacing the System Board
).
4.
Replace the display assembly (see
Replacing the Display Assembly
).
5.
Replace the palm rest (see
Replacing the Palm Rest
).
6.
Replace the keyboard (see
Replacing the Keyboard
).
7.
Replace the module cover (see
Replacing the Module Cover
).
CAUTION:
Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
NOTICE:
To avoid electrostatic discharge, ground yourself by using a wrist grounding strap or by periodically touching an unpainted metal surface (such
as a connector on the back of the computer).
NOTICE:
To help prevent damage to the system board, you must remove the battery from the battery bay before you begin working inside the
computer.
1
coin-cell battery
2
coin-cell battery cable connector
