Dell Latitude CPiA Service Manual 7
+DUG'LVN'ULYH$VVHPEOLHV
Hard-disk drive,
subassembly SUBASSY,HD, xxxxx,I,yyyMM,
CPiA *
6
Hard-disk drive HD, xxxxx,I,yyMM,NBK,zzz *
Hard-disk drive interface
board PWA,INTERCONN,HD,CPiA
Hard-disk drive bracket BRKT,HD,CPiA
+DUG'LVN'ULYH%UDFNHW'RRU$VVHPEO\
Hard-disk drive carrier bracket/
door assembly service kit SVC,ASSY,BRKT/DOOR,
HD,CPiA 6
Hard-disk drive carrier
door DOOR,HD,12.5MM,CPiA
Hard-disk drive carrier
bracket BRKT,HD,12.5MM,CPiA
Hard-disk drive carrier
insulator INSUL,HD,CPiA
Hard-disk drive carrier
screws SCR,M3X3,PHH,LP,ZPS
,5%RDUG
Service kit, I/R board SVC,PWA,FAST IR,CPiA 28
.H\ERDUGV
Keyboard, Belgian KYBD,88,BEL,CPiA 10
Keyboard, Chinese KYBD,87,CHI,CPiA
Keyboard, Danish KYBD,88,DEN,CPiA
Keyboard, French KYBD,88,FR,CPiA
Keyboard, French/Canadian KYBD,87,FR CAN,CPiA
Keyboard, German KYBD,88,GER,CPiA
Keyboard, Italian KYBD,88,ITALIAN,CPiA
Keyboard, Japanese KYBD,90,JPN,CPiA
Keyboard, Korean KYBD,87,KOR,CPiA
Keyboard, Latin American KYBD,88,LAC,CPiA
Keyboard, Norwegian KYBD,88,NOR,CPiA
Keyboard, Portuguese KYBD,88,PORTUGEUSE,CPiA
* Substitute the drive capacity for xxxxx, the drive height for yy, and the
manufacturer for zzz.
7DEOH3DUWVDQG$VVHPEOLHVFRQWLQXHG
3DUWRU$VVHPEO\1DPH 2UGHU1DPH )LJXUH
