Installing Optional HSIM or VHSIM Interface Modules
Optional Installations and Mode Switch Bank Settings B-9
B.5 INSTALLING OPTIONAL HSIM OR VHSIM INTERFACE MODULES
Figure B-5 shows the location of the two connectors for an optional HSIM or VHSIM. Depending
on the HSIM or VHSIM installed, one or both connectors are used.
Figure B-5 HSIM and VHSIM Connector Locations
NOTE
Do not install the optional HSIM or VHSIM without referring to the associated installation
guide.
2600-31 FRONT PANEL
TOP VIEW WITHOUT COVER
Primary
Power
Supply Redundant
Power
Supply
Optional
HSIM or VHSIM
Connectors
