Using LANVIEW
4-2 Troubleshooting
Table 4-1 describes the LED indications and provides recommended actions as appropriate.
Refer to the HSIM or VHSIM user’s guide for a description of the HSIM or VHSIM LED
indications.
NOTE NOTE NOTE NOTE
The terms flashing, blinking, and solid used in Table 4-1 indicate the following:
Flashing indicates an LED is flashing randomly.
Blinking indicates an LED is flashing at a steady rate (approximately 50% on, 50% off).
Solid indicates a steady LED light. No pulsing.
Table 4-1 LANVIEW LEDs
LED Color State Recommended Action
PWR Off Device electronics not
receiving power from
power supply(ies). 1. Ensure that the power cords are plugged
in correctly and that there is power at the
power source.
2. Contact Cabletron Systems for technical
support.
Green Functional. Power
supply(ies) operating
normally. None.
Amber Indicates loss of power
supply redundancy. 1. Ensure that the power cords are plugged
in correctly and that there is power at the
power source.
2. Contact Cabletron Systems for technical
support.
