Using LANVIEW
Troubleshooting 4-3
CPU Off Power off. Power up device.
Red Blinking. Hardware
failure has occurred. Contact Cabletron Systems for technical
support.
Solid. Resetting, normal
power up reset. If the LED remains red for several minutes,
contact Cabletron Systems for technical
support.
Amber Blinking. Crippled. Contact Cabletron Systems for technical
support.
Solid. Testing. If the LED remains amber for several
minutes, contact Cabletron Systems for
technical support.
Green Solid. Functional. None.
Amber
and
Green Booting. Blinks amber
and green while booting. None.
RX
(Receive)
Off No link.
No activity or port in
standby. Port enabled or
disabled.
None.
Green Solid. Link, port enabled,
no activity. None.
Blinking. Link, port
disabled. None.
Amber Flashing. Link, port
enabled, activity. None.
Red Solid. Diagnostic failure. Contact Cabletron Systems for assistance.
Table 4-1 LANVIEW LEDs (Continued)
LED Color State Recommended Action
