Using LANVIEW
4-4 Troubleshooting
TX
(Transmit)
Off Port enabled, and no
activity.
Should flash green every
two seconds indicating
BPDUs being sent if STA
is enabled and there is a
valid link.
1. Ensure that the STA is enabled and that
there is a valid link.
2. Contact Cabletron Systems for technical
support.
Green Flashing. Indicates
activity. Rate indicates
data rate. None.
Amber Blinking. Port in
standby.
Port may be disabled due
to Spanning Tree.
1. Ensure that the port is not disabled.
2. Contact Cabletron Systems for technical
support.
Red Flashing. Indicates
collision rate. None, unless there is a high amount of
activity. In this case, check for network
configuration problems or a defective
device.
Solid. Diagnostic failure. Contact Cabletron Systems for technical
support.
Table 4-1 LANVIEW LEDs (Continued)
LED Color State Recommended Action
