b.



Squeeze all of the contents of the thermal grease packet (provided with the kit) on to the microprocessor thermal-cooling assembly.



2.

Align the microprocessor thermal-cooling assembly in place on the

system board

.




3.

Connect the fan power cable to the system board.



4.

Tighten the four captive screws, labeled "1" through "4," in consecutive order.



5.

Replace the

palm rest

and then replace the

display panel

.




6.

Replace the

button board

and the

EMI shield

.




7.

Replace the

keyboard

.




8.

Replace the

hinge cover

.
