Dell Latitude D510 - Manual (Page 96)

Input current (maximum) 1.7 A (both)
Input frequency 47–63 Hz (both)
Output current:
90 W 4.62 A (maximum at 4-second pulse); 4.62 A
(continuous)
65 W 3.34 A (maximum at 4-second pulse); 3.34 A
(continuous)
Output power 90 W or 65 W
Rated output voltage 19.5 VDC (both)
Dimensions:
Height 34.2 mm (1.35 inches) (90 W)
33.8–34.6 mm (1.34–1.36 inches) (65 W)
Width 60.8 mm (2.39 inches) (90 W)
57.9 mm (2.28 inches) (65 W)
Length 153.4 mm (6.04 inches) (90 W)
137.2 mm (5.40 inches) (65 W)
Weight (with cables) 0.40 kg (1.0 lb) (90 W)
0.30 kg (0.69 lb) (65 W)
Temperature range:
Operating 0° to 35°C (32° to 95°F) (both)
Storage –40° to 65°C (–40° to 149°F) (both)
Physical
14.1-inch display
Height 35.5 mm (1.4 inches)
Width 338.3 mm (13.3 inches)
Depth 273 mm (10.8 inches)
Weight:
With travel module 2.48kg (5.46 lbs) (6 cell)
2.38kg (5.24 lbs) (4 cell)
15-inch display
Height 35.5 mm (1.4 inches)
Width 338.3 mm (13.3 inches)
Depth 273 mm (10.8 inches)
Weight:
With travel module 2.60kg (5.73 lbs)(6 cell)
2.50kg (5.51 lbs)(4 cell)
Environmental
Temperature range:
Operating 0° to 40°C (32° to 104°F)
Storage –40° to 65°C (–40° to 149°F)
Relative humidity (maximum):
Operating 10% to 90% (noncondensing)
Storage 5% to 95% (noncondensing)
Maximum vibration (using a random-vibration
spectrum that simulates user environment):
Operating 0.66 GRMS
Storage 1.30 GRMS
Maximum shock (measured with hard drive in head-
parked position and a 2-ms half-sine pulse):
Operating 142 G, 70 in/s
Storage 163 G, 80 in/s
Altitude (maximum):
Operating – 15.2 to 3048 m (–50 to 10,000 ft)
Storage – 15.2 to 10,668 m (–50 to 35,000 ft)
