System Overview
Dell™ PowerEdge™ 1500SC Systems User's Guide
System Orientation
Front-Panel Indicators and Features
Back-Panel Features
System Features
Supported Operating Systems
Power Protection Devices
Other Documents You May Need
Obtaining Technical Assistance
Your system, which has one- or two-way-capable Intel® Pentium® III microprocessors, is a full-featured server that provides a robust, reliable, platform for
both large and small customers.
This section describes the major hardware and software features of the system, provides information about the indicators on the system's front panel, and
discusses connecting external devices to the system. It also provides information on obtaining assistance from Dell.
System Orientation
When following the procedures in this guide, assume that the locations or directions relative to the system are as shown in Figure 1-1.
Figure 1-1. System Orientation
Front-Panel Indicators and Features
Figure 1 -2 shows the indicators and features located on the front panel.
Figure 1-2. Front-Panel Features
