Video
Video type ATI Rage XL video controller; VGA connector
Video memory 4 MB
Power
DC power supply:
Wattage one 350-W power supply, or up to two 350-W power
supplies in a redundant configuration
(350 usable watts)
Voltage 90-240V, 47/63 Hz
Heat dissipation 1540 BTU/hr maximum per power supply
Maximum inrush current under typical line conditions and over the entire
system ambient operating range, the inrush current
may reach 50 A per power supply
System battery CR2032 3.0-V lithium coin cell
Physical
Height 43.9 cm (17.3 inches)
Width 26.1 cm (10.3 inches)
Depth 59.2 cm (23.3 inches)
Weight 15.8 kg (35 lb), maximum configuration
Environmental
Temperature:
Operating 10° to 35° C (50° to 95° F)
Storage –40° to 65° C (–40° to 149° F)
Relative humidity:
Operating 20% to 80% (noncondensing)
Storage 5% to 95% (noncondensing)
Maximum vibration:
Operating 0.25 G (half-sine wave) at a sweep of 3 to 200 MHz
for 15 minutes
Storage 0.5 G at 3 to 200 Hz for 15 minutes
Maximum shock:
Operating six consecutively executed shock pulses in the
positive and negative x, y, and z axes (one pulse on
each side of the system) of 50 G for up to 2 ms
Storage six consecutively executed shock pulses in the
positive and negative x, y, and z axes (one pulse on
each side of the system) of 71 G for up to 2 ms
Altitude:
Operating -16 to 3,048 m (-50 to 10,000 ft)
Storage -16 to 10,600 m (-50 to 35,000 ft)
NOTE: For the full name of an abbreviation or acronym used in this table, see the Glossary .
