CY7C1334H

Document #: 38-05678 Rev. *B

Page 5 of 13

Interleaved Burst Address Table
(MODE = Floating or V

DD

)

First

Address

A1, A0

Second

Address

A1, A0

Third

Address

A1, A0

Fourth

Address

A1, A0

00

01

10

11

01

00

11

10

10

11

00

01

11

10

01

00

Linear Burst Address Table (MODE = GND)

First

Address

A1, A0

Second

Address

A1, A0

Third

Address

A1, A0

Fourth

Address

A1, A0

00

01

10

11

01

10

11

00

10

11

00

01

11

00

01

10

Cycle Description Truth Table

[2, 3, 4, 5, 6, 7, 8]

Operation

Address

Used

CE

ZZ

ADV/LD

WE

BW

x

OE

CEN

CLK

DQ

Deselect Cycle

None

H

L

L

X

X

X

L

L-H

Tri-State

Continue Deselect Cycle

None

X

L

H

X

X

X

L

L-H

Tri-State

Read Cycle (Begin Burst)

External

L

L

L

H

X

L

L

L-H

Data Out (Q)

Read Cycle (Continue Burst)

Next

X

L

H

X

X

L

L

L-H

Data Out (Q)

NOP/Dummy Read (Begin Burst)

External

L

L

L

H

X

H

L

L-H

Tri-State

Dummy Read (Continue Burst)

Next

X

L

H

X

X

H

L

L-H

Tri-State

Write Cycle (Begin Burst)

External

L

L

L

L

L

X

L

L-H

Data In (D)

Write Cycle (Continue Burst)

Next

X

L

H

X

L

X

L

L-H

Data In (D)

NOP/WRITE ABORT (Begin Burst) None

L

L

L

L

H

X

L

L-H

Tri-State

WRITE ABORT (Continue Burst)

Next

X

L

H

X

H

X

L

L-H

Tri-State

IGNORE CLOCK EDGE (Stall)

Current

X

L

X

X

X

X

H

L-H

-

Sleep MODE

None

X

H

X

X

X

X

X

X

Tri-State

Notes:

2. X = “Don't Care.” H = HIGH, L = LOW. CE stands for ALL Chip Enables active. BWx = 0 signifies at least one Byte Write Select is active, BWx = Valid signifies

that the desired Byte Write Selects are asserted, see Write Cycle Description table for details.

3. Write is defined by BW

[A:D]

, and WE. See Write Cycle Descriptions table.

4. When a write cycle is detected, all I/Os are three-stated, even during byte writes.
5. The DQ pins are controlled by the current cycle and the OE signal. OE is asynchronous and is not sampled with the clock.
6. CEN = H, inserts wait states.
7. Device will power-up deselected and the I/Os in a three-state condition, regardless of OE.
8. OE is asynchronous and is not sampled with the clock rise. It is masked internally during write cycles. During a read cycle DQs and DQP

[A:D]

= Tri-State when

OE is inactive or when the device is deselected, and DQs = data when OE is active.
