Dell Inspiron 3800 - Manual (Page 67)

Appendix 67
Power consumption:
Panel (typical)
Backlight 0.7 W
1.6 W
Controls brightness can be controlled through key
combinations
Keyboard
Number of keys 87 (U.S., Canada, Thailand, and locations
that use traditional Chinese); 88 (Europe);
90 (Japan)
Key travel 3.0 ± 0.5 to –0.2 mm (0.12 ± 0.02 to
–0.0008 inch)
Key spacing 19.05 ± 0.3 mm (0.75 inch ± 0.012 inch)
Layout QWERTY/AZERTY/Kanji
Touch Pad
Interface PS/2 compatible
X/Y position resolution
(graphics table mode) 240 cpi
Size:
Thickness 2.8 mm (0.11 inch) at highest component
Width 55 mm (2.17 inch)
Height 39-mm (1.54-inch) rectangle
Weight 9.02 g (0.29 ounce)
Power:
Supply voltage 5 V ± 10%
Supply current 25 mA (maximum operating current) for
track stick and touch pad combined
ESD in accordance with IEC-801-2
Display (continued)
