Dell Vostro 1710 (Early 2008) - Manual (Page 45)

8. Replace the keyboard (see Replacing the Keyboard ).
9. Replace the hinge cover (see Replacing the Hinge Cover ).
10. Reconnect the antenna to the WLAN card (see Replacing a WLAN Card ).
Camera and Microphone Assembly
Removing the Camera and Microphone Assembly
CAUTION: Before you begin the following procedure, follow the safety instructions that shipped with your
computer.
1. Follow the instructions in Before Working on Your Computer .
2. Disconnect the antenna from the WLAN card (see Removing a WLAN Card ).
3. Remove the hinge cover (see Removing the Hinge Cover ).
4. Remove the keyboard (see Removing the Keyboard ).
5. Remove the display assembly (see Removing the Display Assembly ).
6. Remove the display bezel (see Removing the Display Bezel ).
7. Remove the M2 x 3-mm screw that secures the camera/microphone assembly.
8. Lift the camera/microphone out of the top cover and disconnect the camera/microphone cable.
1 M2 x 3-mm screw (1)
Replacing the Camera and Microphone Assembly
CAUTION: Before you begin the following procedure, follow the safety instructions that shipped with your
computer.
This procedure assumes that you have completed the removal procedure Removing the Camera and Microphone Assembly .
