B.8 USB Port Connector
USB1, USB2, USB3, UBS4: 2 ports USB Connector
PIN DESCRIPTION PIN
DESCRIPTION
1 VCC 2
GND
3 DATA0- 4
DATA1+
5 DATA0+ 6
DATA1-
7 GND 8
VCC
B.9 LAN Connector
CN2: LAN1 State LED Connector
PIN DESCRIPTION PIN
DESCRIPTION
1 SPEED- 2
SPEED+
3 LINK- 4
ACT+
LAN2: 100/1000 LAN RJ45 Connector
PIN DESCRIPTION PIN
DESCRIPTION
1 TX0+ 2
TX0-
3 TX1+ 4
TX1-
5 VCC 6
GND
7 TX2+ 8
TX2-
9 TX3+ 10
TX3-
11 SPEED1000- 12
SPEED100+
13 LINK- 14
ACT+
CN3: LAN2 State LED Connector
PIN DESCRIPTION PIN
DESCRIPTION
1 SPEED1000- 2
SPEED100+
3 LINK- 4
ACT+
