Connectors
Label Function Remark
IDE Ultra ATA100 Primary &
Secondary IDE connectors
40-pin shrouded header
FDD Floppy connector 34-pin shrouded header
LPT Parallel port connector
COM2 Serial port connector DB-9 connector
COM1 Serial port connector 10-pin shrouded header
IR IRDA infrared interface port 5-pin unshrouded header
DVI DVI connector
USB1 USB dual port connector 8-pin unshrouded header
USB2 USB dual port connector 8-pin unshrouded header
USB3 USB dual port connector 8-pin unshrouded header
USB4 USB dual port connector 8-pin unshrouded header
LAN LAN RJ45 connector RJ-45 with LED
KB/MS 6-pin Mini-Din Keyboard & Mouse
connector
PS/2 fixed rear panel mount
KB External 5-pin Header Keyboard
Connector
5-pin Header
CPU_FAN FAN connector 3-pin friction lock headers
PWR_FAN FAN connector 3-pin friction lock headers
S_ATA1 Serial ATA connector 7-pin vertical headers
S_ATA2 Serial ATA connector 7-pin vertical headers
S_ATA3 Serial ATA connector 7-pin vertical headers
S_ATA4 Serial ATA connector 7-pin vertical headers
F_PANEL1 External switches and indicators 14-pin unshrouded header
J_LANLED1 LAN1 LED connectors RJ-45 connector
VGA VGA connector HBD-15 connector
PW ATX _12V Power connector 4-pin keyed header
ATXCTL Backplane to Main board ATX
power control Connector
3-pin friction lock headers
