42 Dell Latitude CP and CPi — Parts Removal and Replacement Guide
5. Repeat steps 1–4 for the right latch.
6. On the base plastic, find the molded label “P.N. ASSY 89501”; then,
using a permanent marker, write “A01” to the right of “89501.”
This revision mark indicates that the latch rework is complete.
2 9"!
*!
1. Remove the bottom case bracket.
2. If you are replacing the left speaker, carefully remove the speaker
wires from the retaining clips along the bracket’s edges.
3. Remove the speaker from the bottom case bracket.
NOTES: When replacing the speaker, follow these guidelines to prevent
damage to the speaker wires:
Orient the speaker in the bottom case so that the speaker wires are facing
upwards.
Route the speaker wires under their retaining clips on the bottom case
bracket.
bump side
wear ribs (2)
