Dell Latitude CP and CPi — Parts Removal and Replacement Guide 21
The palmrest assembly consists of the touch pad and the palmrest.
&
1. Remove the keyboard.
2. Disconnect the touch-pad cable from ZIF connector JP2 on the
system board.
3. Remove the back cover assembly.
4. Remove the following screws securing the palmrest to the computer:
One 5-mm screw inside the computer, adjacent to the thermal cooling
assembly
Two 5-mm screws inside the upper edge of the hard-disk drive bay
(you must remove the hard-disk drive to access these screws)
Three 12-mm screws underneath the front edge of the computer
palmrest assembly
bottom
case assembly
12-mm screws (3)
5-mm screws (2)
5-mm screw
