4
Chateau™ Decorative Gas Appliance
20009543
55"
(1399mm)
9���"
(235mm)
12���"
(311mm)
24���"
(622mm)
C
L
10���"
(267mm)
3/4"
(19mm)
C
L
51���" (1299mm)
*
3/4" (19mm)
34���" (876mm)
29���"
(746mm)
32���"
(829mm)
33���"
(854mm)
*
49���"
(1245mm)
1���"
(35mm)
1/2"
(13mm)
5/8" (16mm)
44���" (1121mm)
37���" (962mm)
5���" (143mm)
10���"
(270 mm)
8"
(203mm)
3���"
(98mm)
6" (152mm) 1"
(25mm)
*
When framing unit on outside wall, flush with the wall,
a 1/4" (6mm) clearance must be allowed on both sides and top of surround.
7172
DVT38s2 specs
4/04
Sides and Top
of Surround
C
L
25
����
”
(649mm)
Glass
25
����
”
(649mm)
Fireplace Dimensions
Fig. 2 Fireplace specifications and framing dimensions for DVT38S2.
Finished Wall 24¹⁄₂” (622 mm)
for Flush Install 16” (406 mm)
I.D. Minimum Clearance to
Combustibles
NOTE: The control box must be located within the same room as the fireplace.
CAUTION: If you are framing with the plan to use
the CHFN0495, CHWC495, CHFPR495 surround
mantel, it is extremely critical to meet the dimen-
sions provided, especially if the mantel is not
available at the time of framing. A framing stud is
allowed to be placed on the inside of the 6” (152
mm) standoff on the side of the unit where the
conduit is located to meet the 24¹⁄₈” ( 613 mm)
critical dimension from the center of the unit.
The unit is certified with a 3” (76 mm) standoff (to
combustible) on the side of the unit where the con-
duit is located, therefore; it is permissible to locate
stud on the inside of the standoff at 3” (76 mm) from
the body of the unit. (Fig. 2a)
NOTE: The 6” (152 mm) standoff is sent out with the
unit for the purpose of making the glass symmetrical
with respect to the overall width of the unit.
Standard Framing
FP1479
full surround mantel
framing
4/04
CL
48���"
(1222 mm)
11/16"
(17 mm)
24���"
(613 mm)
45���"
(1149 mm)
Critical
Dimension
3“ (76 mm)
3 x 12 Control Box Spacer
Framing
Cross Piece
FP1479
Fig. 2a Framing dimensions are critical when framing for the surround
mantel CHFN0495, CHWC495, CHFPR495.
Mantel Surround Framing
NOTE: Noncombustible insula-
tion may be placed behind the
facing material.
Noncombustible Facing
Material
