Replacing the Front USB Panel





1.

Follow the instructions in

Before You Begin

.




2.

Align and slide the front USB panel clamps into the front USB panel clamp slot.



3.

Replace the screw that secures the front USB panel to the front panel.



4.

Connect the front USB panel cables to the system board connector F_USB2 (see

System Board Components

).




5.

Replace the front bezel (see

Replacing the Front Bezel

).




6.

Replace the computer cover (see

Replacing the Computer Cover

).




7.

Connect your computer and devices to electrical outlets, and turn them on.

Back to Contents Page



CAUTION:

Take care not to damage the cable connectors and the cable routing clips when sliding the front USB panel into the front USB panel

clamp slot.
