86 Configuring the I/O Modules
Figure 3-21. 4G Fibre Channel Pass-Through Module
1 SFP Fibre Channel connector (16) 2 Fibre Channel green/amber
indicators (two per port)
3 power indicator 4 status/identification indicator
1
3
2
4
